• PL8 Head 고점도 기어펌프
  • PL8 -polyurethane - general purpose
  • Polyols, Isocyanates, 촉매, 첨가제 및 실리콘에 적합
  • 우수한 효율성(over 99% @ 100 bar)
  • Viscosity :50 - 80.000 cP
  • Capacity rage :0.18 -1,080 L/h
  • Rotational speed : 10 - 250 rpm
  • Max outlet pressure :1,450 psi (100 bar)
  • Operating temperature :10 ~ 180°C
  • Maker : MVV /ITALY
• PL2 Head 고점도 기어펌프
  • PL2 fully stainless steel: PU, general purpose
  • Polyols, Isocyanates, 촉매, 첨가제 및 실리콘에 적합
  • 우수한 효율성(over 99% @ 100 bar)
  • Viscosity :50 - 80,000 cP
  • Capacity rage : 0.06 -1,260 L/h
  • Rotational speed : 10 - 250 rpm
  • Max outlet pressure :2,175 psi (150 bar)
  • Operating temperature :10 ~ 180°C
  • Maker : MVV /ITALY
• PAL Head 고점도 기어펌프
  • PAL - abrasive coloring agents
  • 연마제, 안료, 착색제,탄화물 함유된 액체(calcium carbonate, titanium oxide…)에 적합
  • 최대 파티클 직경 : 150 micron (depending on concentration)
  • Viscosity : 50 - 1,000,000 cP
  • Capacity rage :0.27 - 72 L/h
  • Rotational speed : 10 - 200 rpm
  • Max outlet pressure : 1,450psi (100 bar)
  • Operating temperature :10 ~ 180°C
  • Maker : MVV /ITALY
• PLR Head 고점도 기어펌프
  • PLR - heated casing
  • Polyols, Isocyanates, 촉매, 첨가제, 실리콘에 적합
  • Viscosity : 50 - 80,000 cP
  • Capacity rage : 0.18 - 1,260 L/h
  • Rotational speed : 10 - 250 rpm
  • Max outlet pressure : 1,450 psi (100 bar)
  • Operating temperature :10 ~ 180°C
  • Maker : MVV /ITALY
• PLZ Head 고점도기어펌프
  • PLZ - process metering
  • General purpose industrial duty gear pumps
  • O&G, 석유화학, 발전 및 기타 공정 응용분야에서 다양한 화학 물질의 정확한 측정에 적합
  • Viscosity : 10 - 80,000 cp
  • Capacity rage : 0.2 - 81 L/h
  • Rotational speed : 10 - 300 rpm
  • Max outlet pressure : 1,450psi (100 bar)
  • Operating temperature : -20 ~ 180°C
  • Maker : MVV /ITALY
• PLV Head 고점도 기어펌프
  • PLV - paint industry
  • 특별한 도색 용도 (Spray gun, Robotic systems)
  • 안료, 착색제, 탄화물을 함유한 액체, 산화물 (예: 탄산칼슘, 산화 티타늄등)과 같은 연마 액체에 적합
  • Viscosity : 1 - 100,000 cP
  • Capacity rage : 0.3 - 8cc/rev
  • Rotational speed : 10 - 300 rpm
  • Max outlet pressure : 172 psi (12 bar)
  • Operating temperature :10 ~ 100°C
  • Maker : MVV /ITALY
• PA6/PA7 Head 고점도 기어펌프
  • PA6/7 - hot melt adhesives - one outlet
  • 포장 산업, 라미네이트 생산, 엣지 밴더등의 용도에 사용되는 고온 분야에 적합
  • Viscosity : 50 - 1,000,000 cP
  • Capacity rage : PA6 Pump head_ 0.45-8 cc/rev , PA7 Pump head_ 8-50 cc/rev
  • Rotational speed : 10 - 150 rpm
  • Max outlet pressure : PA6 Pump head_ 2,900 psi (200 bar) ,PA7 Pump head_ 4,350 psi (300 bar)
  • Operating temperature :10 ~ 200°C
  • Maker : MVV /ITALY
• PF2 Head 고점도 기어펌프
  • PF2 - hot melt adhesives - two outlets
  • 포장 산업, 라미네이트 생산, 엣지 밴더등의 용도에 사용되는 고온 분야에 적합
  • PA6/7 과 같으나Multi discharge ports 가 있음
  • Viscosity : 50 - 1,000,000 cP
  • Capacity rage : 0.2 - 12 cc/rev
  • Rotational speed : 10 - 100 rpm
  • Max outlet pressure : 2,900 psi (200 bar)
  • Operating temperature :10 ~ 200°C
  • Maker : MVV /ITALY
• PAx Head 고점도 기어펌프
  • PAx - man made fibers & melted polymers
  • 인조 섬유 및 Melted polymers (Nylon, PP, PA)에 적합
  • Viscosity : 100 - 1,000,000 cP
  • Capacity rage : 0.3 - 200 cc/rev
  • Rotational speed : 10 - 60 rpm
  • Max outlet pressure : 4,350 psi (300 bar)
  • Operating temperature : < 350 ℃
  • Maker : MVV /ITALY
• PFx Head 고점도 기어펌프
  • PFx - man made fibers & melted polymers
  • 인조 섬유 및 Melted polymers (Nylon, PP, PA)에 적합
  • Planetary gear arrangement, multiple discharge ports (up to 16 outlets)
  • Viscosity : 100 - 1,000,000 cp
  • Capacity rage : 0.3 - 100 cc/rev
  • Rotational speed : 10 - 60 rpm
  • Max outlet pressure : 4,350 psi (300 bar)
  • Operating temperature : < 350 °C
  • Maker : MVV /ITALY
